8 April 2013

Serial Communication Tutorial (Part 3)





In the previous two parts of the this tutorial, we went through a number of simple sketches to get you acquainted with the way that the Arduino handles various data types when passed through the Serial COM port. Here are the main themes from part ONE:
  • Stage One:  Echoing data with the Arduino
  • Stage Two: Using Delimiters to split data.
  • Stage Three: Arduino Maths, simple addition
  • Stage Four: Sending a double to an Arduino, and then doubling it.
  • Stage Five: Sending Sensor data from the Arduino to the Serial Monitor

Here are the main themes from Part TWO:

  • Stage Six: ......A simple Processing Sketch
  • Stage Seven:  Arduino and Processing join forces for more fun
  • Stage Eight: A simple project that shows Serial communication from Arduino to Processing

In Part Three - we will reverse the direction of communication and get Processing to send data to the Arduino via a USB cable,

  • Stage Nine: A simple processing sketch that switches an LED on the Arduino
  • Stage Ten:  A processing sketch that reads from a text file
  • Stage Eleven: A processing sketch that reads data from a text file and sends to the Arduino
  • Stage Twelve: A processing sketch that trasmits data from a file to another Arduino via an XBee module.



Stage Nine - Using your computer to switch an LED

In this stage we create a simple Arduino sketch which will receive a simple command from the Processing Sketch to switch an LED. The Processing sketch will allow you to turn an LED on/off by clicking on the Processing Application window. It will detect the press of the mouse, and will send a command to the Arduino via the USB Serial COM port.

Parts Required:
  • Arduino UNO or compatible board
  • USB cable
  • Arduino and Processing IDE (on computer)
Arduino Logo The Arduino Sketch
 1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
/* ===================================================
Simple number reader: Written by ScottC - 07 Apr 2013
Arduino Version: 1.04
======================================================*/

// The onboard LED is on pin # 13
int onboardLED = 13;


void setup() {
// Begin Serial communication
Serial.begin(9600);

//Set the onboard LED to OUTPUT
pinMode(onboardLED, OUTPUT);
}

void loop(){
/* Read serial port, if the number is 0, then turn off LED
if the number is 1 or greater, turn the LED on. */
while (Serial.available() > 0) {
int num=Serial.read()-'0';
if(num<1){
digitalWrite(onboardLED, LOW); //Turn Off LED
} else{
digitalWrite(onboardLED, HIGH); //Turn On LED
}
}
}


Processing icon The Processing Sketch
 1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
/*===========================================================
Toggle Switch: Send Number to Arduino
Written by Scott C on 07 Apr 2013
Processing Version: 2.0b8
=============================================================*/

import processing.serial.*;

Serial comPort;
boolean ledState=false; //LED is off

void setup(){
//Open COM Port for Communication
comPort = new Serial(this, Serial.list()[0], 9600);
background(255,0,0); //Start with a Red background
}

void draw(){
}


void mousePressed() {
//Toggle led ON and OFF
ledState=!ledState;

//If ledState is True - then send a value=1 (ON) to Arduino
if(ledState){
background(0,255,0); //Change the background to green

/*When the background is green, transmit
a value=1 to the Arduino to turn ON LED */
comPort.write('1');
}else{
background(255,0,0); //Change background to red
comPort.write('0'); //Send "0" to turn OFF LED.
}
}



The Video


Stage Ten: Reading from a Text File

We are now going to give the Arduino a rest (for a moment) and concentrate on a Processing Sketch that will read from a text file. Once we learn this skill, we can then build this Processing functionality into our Arduino Projects. Reading from a text file in Processing is actually quite easy if you use the loadStrings() method. However, it is best if you make things easy for yourself by using delimiters. The most common delimitter is a "comma". The comma allows the computer to group information according to your needs.
  • 11,22,33,44,55,66
  • 1,1,2,2,3,3,4,4,5,5,6,6
  • 112,223,334,455,566
The examples above contain the same numbers but are delimitted in different ways.
We are going to import a few different numbers/letters and store them in an array. We will then iterate through the array to display the values within.
So let us now create the text file. Copy and paste the following text into notepad and save the file, but remember where you save it, because we will need to know location and the name of the file in order to read from in.

NotepadIconCopy and Paste into Notepad:
100,200,A,B,C,10.2,0.1,wx,yz,arduinobasics





Save the file
I am going to call my file data.txt, and will be saving it to my D drive, so the file will be located here:
  • D:/data.txt

We will now create the processing sketch to read the text file and display the data on the screen.
We will use the comma delimiters to separate the data so that it displays in the following way:




Processing icon The Processing Sketch
 1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
/* =============================================================
ReadTextFile and Display on Screen:
Written by ScottC on 15th April 2013 using
Processing version 2.0b8

Website: http://arduinobasics.blogspot.com/
Projects: http://arduinobasics.blogspot.com/p/arduino-basics-projects-page.html

References:
Displaying Text: http://processing.org/reference/text_.html
Reading Text File: http://processing.org/reference/loadStrings_.html
=================================================================*/

void setup(){
size(180,250);
background(255);

/* Read the text file */
String[] lines = loadStrings("D:/data.txt");
int numOfLines=lines.length;
for(int i=0;i<numOfLines;i++){

/* Split the data based on a "," delimiter. */
String[] data = splitTokens(lines[i], ",");
int dataCount = data.length;

for(int j=0; j<dataCount; j++){
/* Set the size and colour of the text */
textSize(16);
fill(100,100,255,50+(j*20));

/* Display the text on the screen */
text(data[j],10,16+(16*j));
}
}
}


void draw(){
}

The code above has the ability to display data from multiple lines within the text file, however for simplicity, I have chosen to use a single line. If I wanted to display more than one line, I would have to change the "for-loops".



Stage Eleven: Read Text File and send to Arduino

In stage 10 we used the Processing  programming language to import a line of data from a text file, break-up the line into pieces (based on comma delimiters) and then displayed the data on the Computer Screen. We will now use this knowledge and take it one step further. We will create a text file, import the data using processing, but this time we will send the data to the Arduino. Meanwhile the Arduino will be waiting patiently for this data, and once it receives the data, it will react according to our needs. We are going to keep this simple. The goal is to send two different letters from the Computer to the Arduino. One letter will turn an LED on, and the other letter will turn the LED off. We will also send an integer to tell the Arduino how long to keep the LED on or off.

GOAL:  Turn an LED on and off by reading a text file.
Our first step in this process is to create a text file that will store our important data. We will store two variables in this file. The first variable will be used to tell the Arduino whether we want to turn the LED on or whether we want to turn the LED off. We will use the letter "O" to turn the LED on, and use the letter "X" to turn the LED off.
The second variable will be a time based variable. It will be used to tell the Arduino "how long" to keep the LED on or off. We will store this variable as an integer and will represent time in "milliseconds".
  • 1000 milliseconds = 1 second
It makes sense to keep these two variables as a pair, however we will separate them using a comma delimitter. We will separate each command by putting the variables on a new line. Copy and paste the following data into notepad (or equivalent text editor), and save the file to your harddrive. I have saved this file as

  • D:/LEDdata.txt

NotepadIcon Text File Data: Here is the data to put into your text file (notepad):
X,50
O,45
X,40
O,35
X,30
O,25
X,20
O,15
X,10
O,5
X,10
O,15
X,20
O,25
X,30
O,35
X,40
O,45
X,50
O,55
X,60
O,65
X,70
O,75
X,80
O,85
X,90
O,95
X,100
O,200
X,200
O,200
X,500
O,500
X,500
O,500
X,20
O,20
X,20
O,20
X,20
O,20
X,20
O,20
X,20
O,20
X,200
O,20
X,20
O,20
X,20
O,20
X,20
O,20
X,20
O,20
X,20
O,20
X,200
O,20
X,20
O,20
X,20
O,20
X,20
O,20
X,20
O,20
X,200
O,20
X,20
O,20
X,20
O,20
X,20
O,20
X,20
O,20
X,20
O,20
X,20
O,20
X,20



We will now set up the Arduino to accept data from the Computer and react to the Letters
  • "O" to turn the LED on
  • "X" to turn the LED off
  • "E" will be used to test for a successful Serial connection.
We will also get the Arduino to interpret the second variable which will be used to set the amount of time to keep the LED on or off.


Arduino LogoArduino Code:
 1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
/* Read TextFile Data: Written by ScottC on 24 April 2013
Arduino IDE version: 1.0.4
http://arduinobasics.blogspot.com.au/2013/04/serial-communication-tutorial-part-3.html
*/

/* Global Variables */
byte byteRead; //Used to receive data from computer.
int timeDelay; //time that the LED is On or Off
int maxtimeDelay=10000; //Maximum time delay = 10 seconds
int ledPin=13; //LED connected to pin 13 on Arduino UNO.

void setup() {
//Set pin 13 (ledPin) as an output
pinMode(ledPin, OUTPUT);
// Turn the Serial Protocol ON
Serial.begin(9600);
}

void loop() {
/* check if data has been sent from the computer: */
if (Serial.available()) {
/* read the most recent byte */
byteRead = Serial.read();

switch (byteRead) {
case 69: //This is an enquiry, send an acknowledgement
Serial.println("A");
break;
case 79: //This is an "O" to turn the LED on
digitalWrite(ledPin, HIGH);
break;
case 88: //This is an "X" to turn the LED off
digitalWrite(ledPin, LOW);
break;
case 46: //End of line
//Make sure time delay does not exceed maximum.
if(timeDelay > maxtimeDelay){
timeDelay=maxtimeDelay;
}
//Set the time for LED to be ON or OFF
delay(timeDelay);
Serial.println("S");
timeDelay=0; //Reset timeDelay;
break;
default:
//listen for numbers between 0-9
if(byteRead>47 && byteRead<58){
//number found, use this to construct the time delay.
timeDelay=(timeDelay*10)+(byteRead-48);
}
}
}
}

Our next step is to import the data in the text file into Processing and then send the data to the Arduino. You may want to review Stage 10 of this tutorial for another example of importing text file data into Processing. You may also want to review stage 7 which shows how to receive data from an Arduino.
We will import all of the data from the file when we push a button on the Processing Window, and send this data to the Arduino via the USB cable that is connected to the computer. We are going to use the same COM port that the Computer uses to upload Arduino Sketches, therefore it is important that you close the Arduino Serial Monitor before you run the processing sketch, otherwise you will get an error which states that the COM port is not available.


Processing icon Processing Code:
 1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
/* TextFile Data sender (Stage 11)
Written by ScottC on 24th April 2013
using Processing Version 2.0b8

The full tutorial can be found here:
http://arduinobasics.blogspot.com/2013/04/serial-communication-tutorial-part-3.html
*/

import processing.serial.*;

Serial comPort; //The com port used between the computer and Arduino
int counter=0; // Helps to keep track of values sent.
int numItems=0; //Keep track of the number of values in text file
String comPortString; //String received From Arduino
String textFileLines[]; //Array of text file lines
String lineItems[]; //Array of line items

void setup(){
comPort = new Serial(this, Serial.list()[0], 9600); //Setup the COM port
comPort.bufferUntil('\n'); //Generate a SerialEvent when a newline is received
background(255,0,0); //Start with a Red background
}

/* Draw method is not used in this sketch */
void draw(){
}

//When the mouse is pressed, write an "E" to COM port.
//The Arduino should send back an "A" in return. This will
//generate a serialEvent - see below.
void mousePressed() {
comPort.write("E");
}

void serialEvent(Serial cPort){
comPortString = cPort.readStringUntil('\n');
if(comPortString != null) {
comPortString=trim(comPortString);

/*If the String received = A, then import the text file
change the background to Green, and start by sending the
first line of the text file to the Arduino */
if(comPortString.equals("A")){
textFileLines=loadStrings("D:/LEDdata.txt");
background(0,255,0);
sendLineNum(counter);
}

/*If the the String received = S, then increment the counter
which will allow us to send the next line in the text file.
If we have reached the end of the file, then reset the counter
and change the background colour back to red. */
if(comPortString.equals("S")){
counter++;
if(counter > (textFileLines.length-1)){
background(255,0,0);
counter=0;
} else {
sendLineNum(counter);
}
}
}
}


/*The sendLineNum method is used to send a specific line
from the imported text file to the Arduino. The first
line item tells the Arduino to either switch the LED on or off.
The second line item, tells the Arduino how long to keep the
LED on or off. The full-stop is sent to the Arduino to indicate
the end of the line. */

void sendLineNum(int lineNumber){
lineItems=splitTokens(textFileLines[lineNumber],",");
comPort.write(lineItems[0]);
comPort.write(lineItems[1]);
comPort.write(".");
}


Stage Twelve: To be continued..


I need to finish my XBee tutorial before doing this stage. But am just about to start studying again. So this stage probably won't get completed for another couple of months. But I hope there is enough content to keep you satisfied for the time being.

20 comments:

  1. Great tutorials.
    keep em coming!

    ReplyDelete
    Replies
    1. Thanks Ray... Its only time that is holding me back.

      Delete
    2. I know that feeling.
      Its good of you to take the time you have so far.
      I'll keep checking back.
      Thanks again.

      Delete
  2. Hello,
    I have a project and I wonder if it's feasible...
    I need to establish a connection between a Galaxy Tab (android ) and DFRduino Uno ( it's the same as official ).
    For the Bluetooth I have a DFRobot Bluetooth V3 connected on pin 0(Rx) and 1(Tx).

    I achieved to make a LED blink faster or slower by sending digit between 0 and 9 using an Bluetooth application on Android ( BlueTerm )
    But this is not what I need to do.

    I have already made an app on processing with an interface and 3 sliders ( it works well ) but the bluetooth side is harder :/
    I would like to send the percentage of the sliders on the Arduino board in a separate variable per sliders.
    I saw your tutorials and I was impressed so I wonder if you think I can find what I need in them ?
    ( I mean they are very complete but are there necessary aspect of the project that are not dealt in? )

    Thanks You very much !

    Ps : Sorry if I made mistakes !

    ReplyDelete
  3. Hi xabi,

    I am not 100% sure what part you need help with. But if you want to create your own app on your Android device to communicate with the Arduino over Bluetooth, then I think you will find my Bluetooth tutorials useful. Please note that this is a rather in depth tutorial that runs over 4 parts. My tutorial does not include sliders, so it won't help you on that front, but it will show you how to send variables to the Arduino over Bluetooth, so you will need to adapt my example to suit your needs.

    I hope I have answered your question.
    Regards Scott

    ReplyDelete
    Replies
    1. Thanks you for the answer !
      I was asking if there was an easy way to send a byte from android to arduino by bluetooth. The tutorial you linked is great thanks, I'll surely find what I need in !
      All the best Xabi

      Delete
    2. Hi Xabi,
      Sending the byte is the easy bit. Establishing Bluetooth connectivity on the other hand is where the difficulty lies.

      Good luck
      Scott

      Delete
  4. Thank you for this tuto, great job!

    ReplyDelete
  5. can you tell me what all libraries should i include while running this sketch ? I am getting an error for loadstrings and some other commands that you have used ..
    my email id is - mangalgishreyas@gmail.com

    ReplyDelete
    Replies
    1. You can tell if a library has been used by the use of "include" statements.
      Please note the version of Processing being used, and the links to those commands.
      Processing has been updated since I wrote this tutorial - which may explain the errors you mention. There may be another way of doing the same thing.

      Delete
  6. Great set of tutorials. Really helpful, thanks very much

    ReplyDelete
  7. Hey. I wanted to know if you could help me out with some code that could read from the serial data and store the data into an array in processing.
    And i wanted to know if you could read and write into the serial window using the same processing code.
    -Deeya

    ReplyDelete
    Replies
    1. Hi Deeya,
      Reading Serial data into an array shouldn't be too hard in Processing. The processing website has a good information on how to store data into an array:
      http://processing.org/reference/Array.html

      And here is how to read from the serial port:
      https://www.processing.org/reference/libraries/serial/Serial_read_.html

      You cannot write into the Arduino Serial Monitor window - because the Serial Monitor would prevent Processing from connecting to the Arduino.
      The Arduino uses a single COM port - which can connect to either Processing or to the Serial Monitor window - but not both.
      You can use Processing's print function to display an output to Processing's debug window. But not sure if this is what you need.

      Delete
  8. Hi,

    I am very new with both arduino and processing.

    I have a text file. It can be:
    100,250,10,360,5

    I would like to put all these values in an array in arduino so that I can use later. Several examples in this blog are very close to this problem. Still, I can't figure this out :(

    "Reading from a Text File and Sending to Arduino"-This project seems very close to my one my as my value is above 10, it does not work for me.


    I would really appreciate if i will get any help by any mean.

    ReplyDelete
    Replies
    1. A good way to get help on your particular project is to use the Arduino Forums.
      This way you can post your code and get 1000s of people to help you out.
      It is the most efficient way.

      Delete
  9. hey this is great, super..!
    i had been stuck for 3 days and found the solution from here...
    thanx again and tanx in advance..:)

    ReplyDelete
  10. could you please explain why: timeDelay=(timeDelay*10)+(byteRead-48);

    ReplyDelete
    Replies
    1. Hi tn,

      Let us take the first line of the text file (X,50).
      When the Arduino receives the X, it will turn the LED off.
      However, it does not receive an X, it will receive a byte (88).

      Processing Program will use the comma as a delimiter and will not send this to the Arduino, but it will send the number = 50.

      The Arduino does not receive the number as a whole because processing will send the number 5 and then the number 0 as TEXT. We have to convert these text bytes into an integer on the Arduino side.

      So when it gets the first digit, timeDelay=0.
      So timeDelay x 10 = 0
      You then have to add (byteRead-48) = 5
      And 0+5 = 5.
      So at this stage the time delay is only 5, but we have not received the second number from the computer yet... that is still to come.

      When it gets the second digit , timeDelay is equal to 5.
      You multiply this by 10 = 50.
      And then add (byteRead-48) = 0
      50+0 = 50

      So the final time delay will = 50

      Please make sure to read and work through the entire tutorial to get a better understanding of what I just did. Please start from stage one and then work your way through to this stage. It will help you understand how the Arduino receives data.

      I hope this answered your question.

      Delete
  11. Excellent tutorials, thanks a million :)

    ReplyDelete

Feel free to leave a comment about this tutorial below.
Any questions about your particular project should be asked in the ArduinoBasics forum.

Comments are moderated due to large amount of spam.
